Simply effective.
Folding shutters
Folding shutters can be opened manually in both directions – left or right, following the principle of an accordion. The individual panels in the shutter fold next to each other when opened, taking up very little space. On the other hand, closed shutters blend in with the facade and create a unified look of the building.
These blinds allow for adjusting their position, ensuring appropriate shading and privacy for interior spaces.
Folding mechanisms can be used up to 6 panels, with various infill options.
Type FPE
Shutters with extended aligment with guides.
This is a shading system where individual panels are attached to a mechanism with specialised hinges.
When the shutters are closed, the integrant panels can cover the guides entirely. Profiles are made from aluminium and parts from stainess steel.
This system allows the shutters to be always aligned with the facade and can cover the whole facade.
2 panels
Ceiling hidden fixation.
6 panels
Ceiling hidden fixation.
4 panels
Ceiling hidden fixation.
Type FPE M
Motorized variant of FPE. Linear motors are used in the Driving mechanism of motorised folding stutters.
2 panels
Folding shutters type FPE M motorized
6 panels
Folding shutters type FPE M motorized
4 panels
Folding shutters type FPE M motorized
TYPE FPE LQ44
Class 6 wind resistance according to EN 13659
TYPE FPE Q40
* Alu sheet and Alu perforated sheet can be used on span up to 900 mm, in case of use of bigger thickness of 2 mm and 3 mm respectively
** Specific resistance studies or system adaptations are required for balcony side shutters, loggia closures, free bay closures or when distance from shutter to fixed window/facade is greate
*** For specific H/W dimensions look at the price table. Possible dimensions for use are non blank.
Type FPC
This is a system of folding shutters where the panels are attached to a mechanism within the panel’s frame. The guide is installed above the panel visible, if not integrated into the loggia ceiling. Profiles are made from aluminium. Other metal parts are from stainless steel.
2 panels
6 panels
4 panels
TYPE FPE LQ44
Class 6 wind resistance according to EN 13659
TYPE FPE Q40
* Alu sheet and Alu perforated sheet can be used on span up to 900 mm, in case of use of bigger thickness of 2 mm and 3 mm respectively
** Specific resistance studies or system adaptations are required for balcony side shutters, loggia closures, free bay closures or when distance from shutter to fixed window/facade is greate
*** For specific H/W dimensions look at the price table. Possible dimensions for use are non blank.
PARTIAL (1/3 W1) SASH wind exposure
COMPLETE SASH overwinding protection outside
NO SASH wind exposure
COMPLETE SASH overwinding protection inside
* Alu sheet and Alu perforated sheet can be used on span up to 900 mm, in case of use of bigger thickness of 2 mm and 3 mm respectively
** Specific resistance studies or system adaptations are required for balcony side shutters, loggia closures, free bay closures or when distance from shutter to fixed window/facade is greate
*** For specific H/W dimensions look at the price table. Possible dimensions for use are non blank.
