Canopy for Terraces and Entrances

Canopy for Terraces and Entrances

Modern canopies for terraces and entrances combine functionality, aesthetics, and flexibility. The base of our canopies can be fully customised – with the choice of accessories, colours, and materials such as aluminium and wood. This creates a unique solution that not only protects your entrance or terrace but also complements the architectural style of your home or business space.

Soltec conopy F170

A narrow and long carport is perfect for balconies, narrow terraces, and bridging the space between two buildings.

• Profile: 170/120
• Dimensions on 4 posts: up to 6000x3500x2800
• Dimensions on 6 posts: up to 9000x3000x2800
• Frame: horizontal, ALU frame
• Roof: ISO panels, 2% integrated slope
• Material: aluminium and inox
• Drainage: concealed, 2 water outlets
• 7-year warranty on the structure
• 10-year warranty on ISO panels
• Maximum snow load: 140 kg/m²

Soltec canopy F240

The canopy for larger areas creates a multifunctional space on the terrace or in at the building entrance.

• Profile: 240/150
• Dimensions on 4 posts: up to 6000x6000x2800
• Dimensions on 6 posts: up to 9150x6000x2800
• Frame: horizontal, ALU frame
• Roof: ISO panels, 2% integrated slope
• Material: aluminium and inox
• Drainage: concealed, 2 water outlets
• 7-year warranty on the structure
• 10-year warranty on ISO panels
• Maximum snow load: 140 kg/m²

Soltec canopy G170

A narrow and long carport is ideal for entrances, balconies, and narrow terraces in environments with stronger snow or wind loads. In addition to the ISO panel, it offers the option of installing different roofs: glass or green.

• Profile: 170/120
• Dimensions on 4 posts: up to 7000x3000x2800
• Dimensions on 6 posts: up to 9000x3000x2800
• Frame: horizontal, ALU frame
• Roof: ISO panels, 1.5% visible roof slope, different post heights
• Material: aluminium and inox
• Drainage: concealed, 2 water outlets
• 7-year warranty on the structure
• 10-year warranty on ISO panels

Soltec canopy G240

It covers larger areas over entrances, balconies, and terraces in environments with stronger snow or wind loads. In addition to the ISO panel, it offers the option to install different roofs: glass or green.

• Profile: 240/150
• Dimensions on 4 posts: up to 6000x3000x2800
• Dimensions on 6 posts: up to 9000x3000x2800
• Frame: horizontal, ALU frame
• Roof: ISO panels, 1.5% visible roof slope, different post heights
• Material: aluminium and inox
• Drainage: concealed, 2 water outlets
• 7-year warranty on the structure
• 10-year warranty on ISO panels

Aditional equipment for Canopies for terraces and entrances

Canopies for terraces and entrances offer great customisation, as they can be easily upgraded with various accessories that highlight your personal style and enhance the functionality of the space. Whether you choose decorative elements, LED lights, or solutions for more privacy, you have the option to select those that perfectly fit your preferences and needs.

ZIP Roller Blinds – K130

ZIP roller blinds are designed to protect rectangular surfaces from sunlight, wind, and prying eyes. They are made from aluminium profiles with a 120 x 130 mm cassette, housing a PVC-coated screen fabric. This system allows for light regulation and reduced overheating, with motorised operation controlled via remote control. An optional wind sensor can be added for automatic retraction when wind speeds exceed 40 km/h.

Sliding Panels – H50

Sliding panels, made with an H50 aluminium frame, are mounted on rollers within an upper guide rail and are available as either fixed or sliding walls.
H50 L – features wooden rhomboid slats as infill.
H50 A – uses aluminium slats as infill.
Both types provide stable and long-lasting side protection.

Glass Sliding Panels – Type G1

Made from 10 mm tempered glass, these panels provide protection from wind and rain while maintaining an open and airy feel. They are mounted on rollers within a bottom aluminium sliding track, with transparent vertical rubber seals for enhanced sealing. The panels can slide left, right, or centrally, stopping at end points. A lock can be added for security.

Glass Folding Panels – Type G2

These folding panels allow for full opening and stacking of individual elements, providing maximum space flexibility. Made from 10 mm tempered glass, they feature transparent rubber seals for effective sealing. The panels fold in a harmonica-style system and can also be equipped with a lock for added security.

Brise-Soleil E300

The E300 vertical aluminium louvers (300 x 50 mm) provide dynamic side enclosure. Manual rotation allows for adjustable shading and ventilation, regulating light and heat transmission. The louvers are powder-coated in a selected RAL colour and designed for easy operation.

Fence – Type 1

The 1000 mm high aluminium fence is made of welded horizontal and vertical profiles, secured between posts.
Type 1A – Suitable for spans up to 3.5 m
Type 1B – Suitable for spans up to 4.5 m
Both types are powder-coated in a selected RAL colour.

Vertical Decorative Columns – R120-60

For enhanced aesthetics and shading, larger vertical columns can be replaced with smaller decorative columns (120 x 60 mm). In the SL170 model, a group of 4 columns is installed alongside the frame.

Decorative ALU (Type S1) or WOODEN (Type S2) Ceiling

An additional ceiling can be installed under the F170 carport, made from wooden rhomboid slats of Siberian larch (20 x 70 mm, minimum spacing 20 mm). The wooden slats add a natural and warm appearance to the space. Alternatively, a decorative ceiling made of aluminium slats (30 x 50 mm, minimum spacing 30 mm) can be selected. These slats are powder-coated in a chosen RAL colour, providing a modern and minimalist look.

Box

A box can be installed under the carport, providing a practical enclosed storage space with a door. The width of the box matches the carport, while the length aligns with the roof beam. Two types of boxes are available:
Type L – Filled with wooden slats made of Siberian larch
Type ISO – Filled with ISO panels, 3 cm thick
Different door options are also available.

LED Lights

LED lights are integrated into the carport ceiling, providing functional illumination for the space. The light intensity can be adjusted using a remote control. Available options:
Lengths: 0.5 m, 1 m, and 1.5 m
Light types: Neutral white and warm white

For More Comfort

To enhance comfort and protection, the F170 carport can be upgraded with additional features such as wind, rain, and light sensors. These smart additions automate system operation, ensuring optimal adaptation to weather conditions, extending the lifespan of the structure, and improving the user experience.

Heaters, Sensors, Power outlet, Control (via app or remote)

INOX, aluminium, and Siberian larch – the perfect combination for long-lasting protection

A carport made of aluminium and INOX is an excellent choice due to its exceptional corrosion resistance, ensuring a long lifespan with minimal maintenance. These two premium materials also allow for a modern and elegant design that seamlessly adapts to various architectural styles.

Aluminium has another key advantage – it is light yet strong, which means the carport does not burden the existing foundations and allows for easy installation. This makes it an excellent solution for quick and efficient setup without complicated construction procedures.

Siberian larch wood is an excellent choice for outdoor spaces, as it naturally resists weather conditions, rot, and insects. Due to its density and strength, it offers a long lifespan, even in demanding conditions, while developing a beautiful patina over time that enhances its natural character. In addition to its aesthetic appeal, its durability ensures easy maintenance, making it ideal for terraces, entrances, and other outdoor spaces.
